NEW

T2 IL SERIES
INTERCONNECTED
GRADE 2

The DOREX T2 IL series interconnected tubular lockset  combines modern style, security and durability. Recommended as suite entry door locks in multi-unit residential applications. Simultaneous retraction of both latch and deadbolt provides easy, panic-proof exiting.



FEATURES

  • Conforms to ANSI/BHMA A156.12, Series 4000, Grade 2
  • cULus listed, 3 hour fire-rating
  • UL10C Positive Pressure Rating
  • Meets ADA requirements
  • 1 Year limited warranty
  • For doors 13⁄4– 21⁄8″ (44.5 – 55 mm) thick
  • Non-handed
  • 23⁄8–23⁄4″ (60–70 mm) adjustable backset
  • Stainless steel latch with 1⁄2″ (12.7 mm) throw
  • Solid steel deadbolt with security pin, 1″ (25.4 mm) throw
  • Single action egress
  • Interior escutcheon included
  • 51⁄2″ (140 mm) centre-to-centre installation
  • Concealed mounting screws
  • Single locking function with 6-pin cylinder, Schlage “C” with 2 keys
  • Includes Lina lever with round or square trim
  • Other lever styles available by special order

Full keying services available. Other common and high security keyways available.

FUNCTIONS

55Suite entry, single lock, with single action egress keyed function

FINISHES

15
SATIN NICKEL
19
MATTE BLACK

Other finishes available
Approximate finish simulation, for reference only

LEVER STYLES


L–Lina

LS–Lina (square rose)

Other lever styles available by special order.

DOCUMENTATION

Product Page

downloadT2 IL Series – 01.042

Installation Instructions

downloadT2 IL – Installation Instructions

Templates

downloadT2 IL – Template

Disclaimer
  • We recommend that physical hardware be ordered and verified before starting any preparation, manufacturing or installation work.
  • All product installations must be done by qualified personnel using the proper mounting hardware for the appropriate surface or material.
  • We recommend that installers and manufacturers use the instructions inside the packaging provided by the manufacturer, as the manufacturer reserves the right to make technical changes, modify product or information without prior notice.
  • Do not exceed the maximum weight or dimensions recommended by the manufacturer.
  • All technical documents, drawings and instructions are provided as-is. Customers (primary or secondary) cannot derive any claim based on the use of these documents. No responsibility is or will be assumed.
